CyberView U-1602

The U-1602 is a 16-Port Combo Cat6 KVM Switch. This combo KVM switch features 2 consoles, 1 x local and 1 x remote.

See Detailed KVM Layout

16-Port Combo Cat6 2-console KVM Benefits

• Combo Cat6 KVM with 16 ports in 1U
• Up to 131 feet (40 m) between your servers & KVM ports
• Remote access up to 492 feet (150 m)
• Cascade switches up to 8 levels & Mix switches between Cat6 & Combo DB-15 KVM
• Support HDMI, DisplayPort, DVI, VGA-USB & VGA-PS/2 server interface
• Mix PS/2, USB & SUN with Multi-Platform switch capability

Switch Features & Options

• Multi lingual on screen display menu
• Advanced user profiles and configurable OSD hot key combinations
• Dual power with failover

U-1602 Layout

U-1602 Rear Diagram

U-1602 Front Diagram

_TALK TO AN EXPERT

CyberView U-1602 Highlights

•

  Integrated CATx extender
  (1 Remote Users)

  The U-1602 Cat6 Combo KVM can be controlled by one user from up to 500ft (150m) away over CATx cable using the integrated CATx extender with the included KVM receiver.

  • 1920 x 1200@60Hz (100ft)
  • 1920 x 1080@60Hz (150ft)
  • 1600 x 1200@60Hz (300ft)
  • 1280 x 1024@60Hz (500ft)
•

  VGA, DVI, HDMI & DisplayPort sources
  from up to 130 feet away

  U-1602 supports any combination of VGA, DVI, HDMI, DisplayPort, USB, and PS/2 sources through low-cost KVM dongles. Source computers can be located up to 130 feet (40 m) away via Cat5/6 cable.

  Compare CAMs

•

  Multi-user access & management

  One local user or one extended user can control 16 multi-platform servers. Expand up to 256 source computers simply by linking Cat6 Combo KVMs.



•

  Multi-platform support

  The CyberView Cat6 Combo KVM switches support any computer platform with USB, PS/2, or Sun keyboard and mouse interfaces, including all versions of Windows, Mac, Linux & SUN systems.

•

  Channel selection options

  The CyberView U-1602 can be switched using selectable keyboard hotkeys, front-panel push buttons, or with a mouse through an on-screen-display (OSD). These switching options allow you to quickly reassign connected devices to any of the connected computers.

•

  Hot pluggable, no software or drivers required

  Add PCs or remove connected PCs for maintenance without powering down the KVM switch or PCs. CyberView KVMs are designed to be driver & software-free.



•

  Easy Expansion
  (Cascading Units)

  Expand up to 256 source computers simply by linking Cat6 Combo KVM units using CBC-6 cables. The U-1602 KVM automatically detects up to 8 levels of cascade connections, which can be made up of a mix of U-801 / U-1601 / U-3201 KVM switches.

•

  Redundant AC OR Optional DC power

  For mission critical applications, Cat6 Combo series now supports dual power inlets (Dual-AC). If one source fails, the U-1602 will switch sources so as not to interrupt normal use of the connected servers. Alternatively, customers can also get DC power input integrated into the KVM.

•

  1U rack mount OR Integrate into rack drawer

  CyberView U-1602 KVM switch can be rack mounted into 1U of space (rack brackets included), or it can be purchased integrated into a CyberView Rack Console. Small size also makes the units ideal for mounting behind third-party rack console.

U-1602 Specifications

U-1602 KVM Hot Key Sequences

U-1602 is also known as:

• U1602
