SmartAVI UX-RXPLUS
• Discontinued ⓘ
This product has been discontinued by the manufacturer and is no longer available for purchase.
Looking for a replacement or comparable alternative?
Request Options
Lead time and availability are subject to change without notice.
Product Code:
UX-RXPLUS
Start Call for Price Product View Page short code
Ended Call for Price Product View Page short code
Extends & Splits WUXGA Video & USB 1.1 Keyboard & Mouse up to 500 ft over CAT5 Cable, Receiver only
The SmartAVI UX-RXPLUS is a WUXGA+USB Receiver. It Includes the receiver and the PS5VDC2A power supply. Please note, to operate correctly this receiver requires a transmitter (sold separately).
The UX-PLUSS (full system with receiver and transmitter) extends and splits WUXGA Video and USB 1.1 Keyboard and Mouse up to 500 feet over CAT5 Cable.
SmartAVI UX-RXPLUS Backview
SmartAVI UX-RXPLUS Features:
- Supports WUXGA video extension for resolutions up to 1920 x 1200
- Local WUXGA output for a local display
- Plug and play, no software required
- Fully compliant with USB 1.1 specifications for Keyboard and Mouse
- Built-in skew compensation
- Uses a single CAT5 UTP cable up to 500 feet
- External power adapter for transmitter and receiver unit
- Fully transparent (does not use any emulation)
SmartAVI UX-RXPLUS Application Diagram
SmartAVI UX-RXPLUS Specifications:
| Mechanical | |
| Width | 5.0 in. (12.7 cm.) |
| Height | 1.0 in. (2.5 cm.) |
| Depth | 3.0 in. (7.6 cm.) |
| Weight | 1.0 lb. (0.45 kg.) |
| Video | |
| Format | RGBHV, RGsB, YUV, Y/C, CVBS |
| Resolution | Up to 1920x1200 VGA, SVGA, XGA, SXGA, UXGA, WUXGA |
| Input Interface (TX) | (1) HD-15 Male / USB |
| Ouptut Interface (TX) | (1) HD-15 Female (For local display) |
| Ouptut Interface (RX) | (1) HD-15 Female |
| USB | |
| Signaling | USB 1.1, and 1.0 |
| Input Interface | (2) USB Type A (Female) (for local keyboard and mouse) |
| Ouput Interface | (2) USB Type A (Female) |
| Power | External 100-240 VAC 5VDC2A @ 10W |
| Environmental | |
| Operating Temperature | 32-131F (0-55C) |
| Storage Temperature | -4-185F (20-85C) |
| Humidity | Up to 95% |
| Approvals | UL, CE, ROHS Compliant |
*Please note that the specifications above also include the facts concerning the transmitter. This product being sold on this page is only the receiver.
